Reactor vessel delivered for China's first HTR

15 March 2016

The first of two reactor pressure vessels for the demonstration HTR-PM high-temperature gas-cooled reactor unit under construction at Shidaowan in China's Shandong province has been delivered to the construction site.

HTR vessel delivered - 460 (CHNG)
The vessel arrives at Shidaowan (Image: China Huaneng)

The component - about 25 meters in height and weighing about 700 tonnes - was manufactured by Shanghai Electric Nuclear Power Equipment. It successfully completed factory acceptance on 29 February and was dispatched from the manufacturing plant on 2 March. The pressure vessel arrived at the Shidaowan site on 10 March, plant owner China Huaneng Group announced the following day.

The company said it sent the project leader and supervision staff to supervise the entire manufacturing process of the reactor vessel, which it claims is the world's largest and heaviest.

Work began on the demonstration HTR-PM unit - which features two small reactors and a turbine - at China Huaneng's Shidaowan site in December 2012. China Huaneng is the lead organization in the consortium to build the demonstration units together with China Nuclear Engineering Corporation (CNEC) and Tsinghua University's Institute of Nuclear and New Energy Technology, which is the research and development leader. Chinergy, a joint venture of Tsinghua and CNEC, is the main contractor for the nuclear island.

The demonstration plant's twin HTR-PM reactors will drive a single 210 MWe turbine. It is expected to start commercial operation in late 2017. An earlier proposal was for 18 further 210 MWe units - giving a total capacity of 3800 MWe - at the Shidaowan site, near Rongcheng in Weihai city, but this has been dropped.

A proposal to construct two 600 MWe HTR plants - each featuring three twin reactor and turbine units - at Ruijin city in China's Jiangxi province passed a preliminary feasibility review in early 2015. The design of the Ruijin HTRs is based on the smaller Shidaowan demonstration HTR-PM. Construction of the Ruijin reactors is expected to start next year, with grid connection in 2021.

Researched and written
by World Nuclear News
